Description
| Model | Crane | Rectangular Steel tube |
Wheel Size | Motor power | S1 (mm) |
S2 (mm) |
W1 (mm) |
W2 (mm) |
H (mm) |
| L125-15 | 1t-7.5m | 150*150*6 | W125*60 | 0.3KW*2 | 1500 | 1300 | 400 | 500 | 162.5 |
| L125-20 | 1t-11.5m | 2000 | 1800 | 400 | 500 | 162.5 | |||
| L125-25 | 1t-16.5m | 2500 | 2300 | 400 | 500 | 162.5 | |||
| L160-15 | 2t/3t-7.5m | 150*200*8 | W160*70 | 0.4KW*2 | 1500 | 1200 | 400 | 500 | 215 |
| L160-20 | 2t/3t-11.5m | 2000 | 1700 | 400 | 500 | 215 | |||
| L160-25 | 2t/3t-16.5m | 2500 | 2200 | 400 | 500 | 215 | |||
| L160-30 | 2t/3t-22.5m | 3000 | 2700 | 500 | 600 | 215 | |||
| L160-35 | 2t/3t-28.5m | 3500 | 3200 | 600 | 700 | 215 | |||
| L200-20 | 5t-11.5m | 150*250*8 | W200*70 | 0.4KW*2 | 2000 | 1700 | 400 | 500 | 265 |
| L200-25 | 5t-16.5m | 2500 | 2200 | 400 | 500 | 265 | |||
| L200-30 | 5t-22.5m | 0.75KW*2 | 3000 | 2700 | 500 | 600 | 265 | ||
| L200-35 | 5t-28.5m | 3500 | 3200 | 600 | 700 | 265 | |||
| L250-20 | 10t-11.5m | 200*250*8 | W250*80 | 0.75KW*2 | 2000 | 1600 | 400 | 500 | 280 |
| L250-25A | 10t-16.5m | 2500 | 2100 | 500 | 600 | 280 | |||
| L250-30A | 10t-22.5m | 1.1KW*2 | 3000 | 2600 | 500 | 600 | 280 | ||
| L250-35A | 10t-28.5m | 3500 | 3100 | 700 | 800 | 280 | |||
| L250-25B | 16t-16.5m | 200*300*8 | W250*80 | 1.1KW*2 | 2500 | 2100 | 600 | 700 | 330 |
| L250-30B | 16t-22.5m | 3000 | 2600 | 700 | 800 | 330 | |||
| L250-35B | 16t-28.5m | 1.5KW*2 | 3500 | 3100 | 700 | 800 | 330 | ||
| L315-30 | 20t-16.5m | 200*400*8 | W315*90 | 1.5KW*2 | 3000 | 2500 | 700 | 800 | 430 |
| L315-35 | 20t-22.5m | 3500 | 3000 | 700 | 800 | 430 |
