Description
| Items | Parameters | Messurement Unit | |
| Rated Working Pressure | 0.6-0.8 | MPa | |
| Rated Full Force | 50 | KN | |
| Rated Cable Speed | 12 | m/min | |
|
Piston Air Motor |
Model | TMH17 | — |
| Rated Power | 17 | KW | |
| Air Consumption | 247 | L/s | |
|
Drum |
Diameter | 222 | mm |
| Width | 335 | mm | |
| Wheel Rim Diameter | 465 | mm | |
| Cable Diameter | 16 | mm | |
| Cable Storage | 120 | m | |
| Air Inlet Diameter | 1 1/4 | inch | |
| Configuration ( Length* Width* Height) ) | 1250mm*770mm*1016mm | ||
| Weight | 518 | KG | |
| Brake Type | Hand Brake and Auto Band Brake | ||
