Description
| Model | HSF 1.0 | HSF 1.5 | |
| Rated lifting capacity | kg | 1000 | 1500 |
| Max.lifting height | mm | 1600 | 1600 |
| Lowered height of forks | mm | 90 | 90 |
| Fork length | mm | 900 | 900 |
| Adjustable width of forks | mm | 320*1200 | 340*1200 |
| Lifting speed | mm/stroke | 20 | 20 |
| Lowering speed | mm/stroke | Adjustable | Adjustable |
| Operation power of crank | kg | 24 | 24 |
| Outer width of front legs | mm | 1400 | 1400 |
| Front wheel size | mm | Φ74*52 | Φ74*52 |
| Rear wheel size | mm | Φ180*50 | Φ180*50 |
| Overall size | mm | 1390*1400*2040 | 1390*1400*2040 |
| Weight | kg | 210 | 250 |
