Description
| Model | Crane | Rectangular Steel tube |
Wheel size | Motor power （20m/min) |
Motor power （30m/min) |
S1 (mm) |
S2 (mm) |
W1 (mm) |
W2 (mm) |
H (mm) |
| UL90-15 | 1.6t-7.5m | 150*150*6 | U90*60 | FA27-0.25KW | FA27-0.37KW | 1500 | 1300 | 400 | 550 | 212.5 |
| UL90-20 | 1.6t-11.5m | 2000 | 1800 | 400 | 550 | 212.5 | ||||
| UL90-25 | 1.6t-16.5m | 2500 | 2300 | 400 | 550 | 212.5 | ||||
| UL90-30 | 1.6t-22.5m | 3000 | 2800 | 400 | 550 | 212.5 | ||||
| UL125-15 | 3.2t-7.5m | 150*200*8 | U125*60 | FA27-0.37KW | FA27-0.55KW | 1500 | 1300 | 400 | 550 | 212.5 |
| UL125-20 | 3.2t-11.5m | 2000 | 1800 | 400 | 550 | 212.5 | ||||
| UL125-25 | 3.2t-16.5m | 2500 | 2300 | 400 | 550 | 270 | ||||
| UL125-30 | 3.2t-22.5m | 3000 | 2800 | 500 | 650 | 270 | ||||
| UL125-35 | 3.2t-28.5m | 3500 | 3300 | 600 | 750 | 270 | ||||
| UL160-15 | 6.3t-7.5m | 150*250*8 | U160*70 | FA37-0.55KW | FA37-0.75KW | 1500 | 1200 | 400 | 550 | 270 |
| UL160-20 | 6.3t-11.5m | 2000 | 1700 | 400 | 550 | 270 | ||||
| UL160-25 | 6.3t-16.5m | 2500 | 2200 | 400 | 550 | 320 | ||||
| UL160-30 | 6.3t-22.5m | 3000 | 2700 | 500 | 650 | 320 | ||||
| UL160-35 | 6.3t-28.5m | 3500 | 3200 | 600 | 750 | 320 | ||||
| UL200-20 | 12.5t-11.5m | 200*250*8 | U200*70 | FA47-0.75KW | FA47-1.1KW | 2000 | 1700 | 500 | 650 | 320 |
| UL200-25 | 12.5t-16.5m | 2500 | 2200 | 500 | 650 | 425 | ||||
| UL200-30 | 12.5t-22.5m | FA47-1.1KW | 3000 | 2700 | 600 | 750 | 425 | |||
| UL200-35 | 12.5t-28.5m | 3500 | 3200 | 700 | 850 | 425 | ||||
| UL250-20 | 16t/20t-11.5m | 200*300*8 | U250*80 | FA57-1.1KW | FA57-1.5KW | 2000 | 1600 | 500 | 650 | 425 |
| UL250-25 | 16t/20t-16.5m | 2500 | 2100 | 600 | 750 | 430 | ||||
| UL250-30 | 16t/20t-22.5m | FA57-1.5KW | 3000 | 2600 | 700 | 850 | 430 | |||
| UL250-35 | 16t/20t-28.5m | 3500 | 3100 | 700 | 850 | 430 |
